2.3.2.1 The DBMS_SQL. OPEN_CURSOR function

Use this function to open a cursor. Here's the specification:

FUNCTION DBMS_SQL.OPEN_CURSOR RETURN INTEGER;

Notice that you do not provide a name for the cursor. You are simply requesting space in shared memory for the SQL statement and the data affected by that statement.

You can use a cursor to execute the same or different SQL statements more than once. When you reuse a cursor, the contents of the cursor data area are reset if a new SQL statement is parsed. You do not have to close and reopen a cursor before you reuse it. You absolutely do not have to open a new cursor for each new dynamic SQL statement you want to process. When you are done with the cursor, you should remove it from memory with a call to the CLOSE_CURSOR procedure.

The following example demonstrates the use of a single cursor for two different SQL statements. I declare a cursor, use it to create an index, and then use it to update rows in the emp table.

CREATE OR REPLACE PROCEDURE do_two_unrelated_actions     (tab_in IN VARCHAR2, col_in IN VARCHAR2, val_in IN NUMBER) IS    cur BINARY_INTEGER := DBMS_SQL.OPEN_CURSOR;    fdbk BINARY_INTEGER;    BEGIN    /* Piece together a CREATE INDEX statement. */    DBMS_SQL.PARSE (cur,        'CREATE INDEX ind_' || tab_in || '$' || col_in || ' ON ' ||       tab_in || '(' || col_in || ')',       DBMS_SQL.NATIVE);    fdbk := DBMS_SQL.EXECUTE (cur);     /* Use the same cursor to do the update. */    DBMS_SQL.PARSE (cur,       'UPDATE ' || tab_in || ' SET ' || col_in || ' = :newval',       DBMS_SQL.NATIVE);    DBMS_SQL.BIND_VARIABLE (cur, 'newval', val_in);    fdbk := DBMS_SQL.EXECUTE (cur);        /* Free up the memory from the cursor. */    DBMS_SQL.CLOSE_CURSOR (cur); END; /

2.3.2.2 The DBMS_SQL.IS_OPEN function

The IS_OPEN function returns TRUE if the specified cursor is already open, and FALSE if the cursor has been closed or if the value does not point to a dynamic cursor,

FUNCTION DBMS_SQL.IS_OPEN (c IN INTEGER) RETURN BOOLEAN;

where c is the pointer to the cursor. This function corresponds to the %ISOPEN attribute for regular PL/SQL cursors.

2.3.3.1 The DBMS_SQL.PARSE procedure

The PARSE procedure immediately parses the statement specified. It comes in two formats. The first, as follows, will be used in almost every case. For very large SQL statments, use the PL/SQL table-based version described in the next section.

PROCEDURE DBMS_SQL.PARSE     (c IN INTEGER,     statement IN VARCHAR2,     language_flag IN INTEGER);

The parameters for this procedure are summarized in the following table.

Parameter	Description
c	The pointer to the cursor or memory area for this SQL statement.
statement	The SQL statement to be parsed and associated with the cursor. This statement should not be terminated with a semicolon unless it is a PL/SQL block.
language_flag	A flag determing how Oracle will handle the statement. Valid options are DBMS_SQL.V6, DBMS_SQL.V7, and DBMS_SQL.NATIVE. Use DBMS_SQL.NATIVE unless otherwise instructed by your DBA.

Note that you cannot defer the parsing of this statement, as is possible with OCI. Statements in DBMS_SQL are parsed immediately. Oracle documentation does mention that this "may change in future versions; you should not rely on this behavior." This means that at some point in the future, Oracle Corporation may allow parsing to be deferred to the execute phase, thereby reducing network traffic. If this change occurs, let's hope that a flag is offered to preserve earlier functionality.

NOTE: The common understanding among long-time Oracle programmers is that when you parse DDL, it always executes, so a call to the EXECUTE procedure is not necessary when calling DBMS_SQL.PARSE for a DDL statement. You should not take this shortcut! Oracle will not guarantee that this behavior will continue in future releases. If you want to make sure that your DDL has executed, call the DBMS_SQL.EXECUTE procedure.

2.3.3.2 Parsing very l ong SQL statements

PL/SQL8 offers a second, overloaded version of PARSE, which comes in handy when you have very large SQL statements. If your SQL statement exceeds the largest possible contiguous allocation on your system (and it is machine-dependent) or 32Kbytes (the maximum size for VARCHAR2), then use this version of the PARSE procedure:

PROCEDURE DBMS_SQL.PARSE    (c IN INTEGER,     statement IN DBMS_SQL.VARCHAR2S,     lb IN INTEGER,     ub IN INTEGER,     lfflg IN BOOLEAN,     language_flag IN INTEGER);

The parameters for this procedure are summarized in the following table.

Parameter	Description
c	The pointer to the cursor or memory area for this SQL statement.
statement	The SQL statement to be parsed and associated with the cursor. In this case, you will be passing a PL/SQL table of the DBMS_SQL.VARCHAR2S type.
lb	The lower bound or first row in the statement table to be parsed.
ub	The upper bound or last row in the statement table to be parsed.
lfflg	If TRUE, then a line-feed should be concatenated after each row in the table.
language_flag	A flag determining how Oracle will handle the statement. Valid options are DBMS_SQL.V6, DBMS_SQL.V7, and DBMS_SQL.NATIVE. Use DBMS_SQL.NATIVE unless otherwise instructed by your DBA.

My own parse_long_one procedure offers an example of using the array-based version of the PARSE procedure:

/* Filename on companion disk:

parslong.sp */ CREATE OR REPLACE PROCEDURE parse_long_one     (select_list IN VARCHAR2,     from_list IN VARCHAR2,     where_clause IN VARCHAR2,     maxlen IN BINARY_INTEGER := 256, /* Can change the max. */     dbg IN BOOLEAN := FALSE /* Built-in debugging toggle */    ) IS    /* Open the cursor as I declare the variable */    cur BINARY_INTEGER := DBMS_SQL.OPEN_CURSOR;        /* Declare the index-by table based on the DBMS_SQL TYPE. */    sql_table DBMS_SQL.VARCHAR2S;        /* Local module to extract up to the next maxlen chars. */    FUNCTION next_row        (string_in IN VARCHAR2,         start_inout IN OUT BINARY_INTEGER,        len_in IN BINARY_INTEGER)    RETURN VARCHAR2    IS       v_start BINARY_INTEGER := start_inout;    BEGIN       start_inout := LEAST (len_in + 1, start_inout + maxlen);       RETURN SUBSTR (string_in, v_start, maxlen);    END;        /* Local module to transfer string to index-by table. */    PROCEDURE fill_sql_table (string_in IN VARCHAR2)    IS       v_length BINARY_INTEGER;       v_start BINARY_INTEGER := 1;    BEGIN       IF string_in IS NOT NULL       THEN          v_length := LENGTH (string_in);          LOOP             sql_table (NVL (sql_table.LAST, 0)+1) :=                 next_row (string_in, v_start, v_length);             EXIT WHEN v_start > v_length;          END LOOP;       END IF;    END;      BEGIN    /* Move each portion of the SELECT string to the table. */    fill_sql_table (select_list);    fill_sql_table (from_list);    fill_sql_table (where_clause);        /* Parse everything from first to last row of table. */    DBMS_SQL.PARSE (cur,        sql_table, sql_table.FIRST, sql_table.LAST,       FALSE, DBMS_SQL.NATIVE);          /* Execute and fetch rows if doing something for real... */     /* If debugging, then display contents of the table. */       IF dbg    THEN       DBMS_OUTPUT.PUT_LINE           ('Parsed into lines of length ' || TO_CHAR (maxlen));       FOR rowind IN sql_table.FIRST .. sql_table.LAST       LOOP          DBMS_OUTPUT.PUT_LINE (sql_table(rowind));       END LOOP;    END IF;        /* Close the cursor when done. */    DBMS_SQL.CLOSE_CURSOR (cur); END; /

Here is a little test script (and the results of execution) for this procedure:

SQL> BEGIN parse_long_one ('select empno, ename, sal, hiredate, mgr, comm ',    'from emp ', 'where empno = empno and sal = sal', 10, TRUE); END; /  Parsed into lines of length 10 select emp no, ename, sal, hire date, mgr, comm from emp where empn o = empno and sal = sal /

Notice that the SELECT statement is broken without any concern for keeping identifiers intact. The lfflg value passed in to the PARSE procedure is set to FALSE so linefeeds are not concatenated. As a result, the broken identifiers are concatenated back together and the SQL statement parses without any difficulty.

2.3.4.1 The DBMS_SQL.BIND_VARIABLE procedure

The BIND_VARIABLE procedure binds a scalar value to a placeholder in your SQL statement. A placeholder is an identifier prefaced by a colon, as in :myval. Call BIND_VARIABLE after DBMS_SQL.PARSE, but before calls to EXECUTE and EXECUTE_AND_FETCH. This procedure is overloaded to allow you to bind a number of different types of data. This is the header:

PROCEDURE DBMS_SQL.BIND_VARIABLE    (c IN INTEGER,     name IN VARCHAR2,     value IN <datatype>);

The parameters for this procedure are summarized in the following table.

Parameter	Description
c	The handle or pointer to the cursor originally returned by a call to OPEN_CURSOR.
name	The name of the placeholder included in the SQL statement passed to PARSE.
value	The value to be bound to the placeholder variable.

<datatype> may be any of the following:

BFILE BLOB CLOB CHARACTER SET ANY_CS DATE MLSLABEL /*Trusted Oracle only*/ NUMBER VARCHAR2 CHARACTER SET ANY_CS_ARRAY

Here is an example of binding the current date/time into a placeholder called "now:"

DBMS_SQL.BIND_VARIABLE (cur, 'now', SYSDATE);

Here is an example of binding the literal value "Liberation Theology" into a placeholder called "progress:"

DBMS_SQL.BIND_VARIABLE (cur, ':progress', 'Liberation Theology');

Notice that you can include or leave out the colon when you specify the placeholder name.

The DBMS_SQL package also offers more specific variants of BIND_VARIABLE for less-common datatypes,

PROCEDURE DBMS_SQL.BIND_VARIABLE    (c IN INTEGER,      name IN VARCHAR2,      value IN VARCHAR2 CHARACTER SET ANY_CS,     [,out_value_size IN INTEGER]);  PROCEDURE DBMS_SQL.

BIND_VARIABLE_CHAR    (c IN INTEGER,      name IN VARCHAR2,      value IN CHAR CHARACTER SET ANY_CS,     [,out_value_size IN INTEGER]);  PROCEDURE DBMS_SQL.

BIND_VARIABLE_RAW    (c IN INTEGER,      name IN VARCHAR2,      value IN RAW     [,out_value_size IN INTEGER]);  PROCEDURE DBMS_SQL.

BIND_VARIABLE_ROWID    (c IN INTEGER,      name IN VARCHAR2,      value IN ROWID);

where out_value_size is the maximum size expected for the value that might be passed to this variable. Square brackets indicate optional parameters. If you do not provide a value for out_value_size, the size is the length of the current value provided.

2.3.5.1 The DBMS_SQL. DEFINE_COLUMN procedure

When you call the PARSE procedure to process a SELECT statement, you need to pass values from the database into local variables. To do this, you must tell DBMS_SQL the datatypes of the different columns or expressions in the SELECT list by making a call to the DEFINE_COLUMN procedure:

PROCEDURE DBMS_SQL.DEFINE_COLUMN     (c IN INTEGER,      position IN INTEGER,      column IN <datatype>);

The parameters for this procedure are summarized in the following table.

Parameter	Description
c	Pointer to the cursor.
position	The relative position of the column in the SELECT list.
column	A PL/SQL variable or expression whose datatype determines the datatype of the column being defined. The particular value being passed in is irrelevant.

<datatype> may be one of the following data types: NUMBER , DATE , MLSLABEL , BLOB , CLOB CHARACTER SET ANY_CS , BFILE

The DBMS_SQL package also offers more specific variants of DEFINE_COLUMN for less-common datatypes.

PROCEDURE DBMS_SQL.DEFINE_COLUMN      (c IN INTEGER     ,position IN INTEGER     ,column IN VARCHAR2 CHARACTER SET ANY_CS     ,column_size IN INTEGER);  PROCEDURE DBMS_SQL.

DEFINE_COLUMN_CHAR      (c IN INTEGER     ,position IN INTEGER     ,column IN CHAR CHARACTER SET ANY_CS     ,column_size IN INTEGER);  PROCEDURE DBMS_SQL.

DEFINE_COLUMN_RAW     (c IN INTEGER     ,position IN INTEGER     ,column IN RAW     ,column_size IN INTEGER);  PROCEDURE DBMS_SQL.

DEFINE_COLUMN_ROWID     (c IN INTEGER     ,position IN INTEGER     ,column IN ROWID);  PROCEDURE DBMS_SQL.DEFINE_COLUMN_LONG     (c IN INTEGER     ,position IN INTEGER);

You call DEFINE_COLUMN after the call to the PARSE procedure, but before the call to EXECUTE or EXECUTE_AND_FETCH. Once you have executed the SELECT statement, you will then use the COLUMN_VALUE procedure to grab a column value from the select list and pass it into the appropriate local variable.

The following code shows the different steps required to set up a SELECT statement for execution with DBMS_SQL:

DECLARE    /* Declare cursor handle and assign it a pointer */    c INTEGER := DBMS_SQL.OPEN_CURSOR;     /* Use a record to declare local structures. */    rec employee%ROWTYPE;     /* return value from EXECUTE; ignore in case of query */    execute_feedback INTEGER; BEGIN    /* Parse the query with two columns in SELECT list */    DBMS_SQL.PARSE        (c,         'SELECT employee_id, last_name FROM employee',        DBMS_SQL.V7);     /* Define the columns in the cursor for this query */    DBMS_SQL.DEFINE_COLUMN (c, 1, rec.empno);    DBMS_SQL.DEFINE_COLUMN (c, 2, rec.ename, 30);     /* Now I can execute the query */    execute_feedback := DBMS_SQL.EXECUTE (c);    ...    DBMS_SQL.CLOSE_CURSOR (c) END;

Notice that with the DEFINE_COLUMN procedure, you define columns (their datatypes) using a sequential position. With BIND_VARIABLE, on the other hand, you associate values to placeholders by name.

2.3.5.2 The DBMS_SQL.DEFINE_ARRAY procedure

If you are working with PL/SQL8, you have the option of defining a column in the cursor which is capable of holding the values of multiple fetched rows. You accomplish this with a call to the DEFINE_ARRAY procedure:

PROCEDURE DBMS_SQL.DEFINE_ARRAY     (c IN INTEGER     ,position IN INTEGER     ,<table_parameter> IN <table_type>     ,cnt IN INTEGER     ,lower_bound IN INTEGER);

The DEFINE_ARRAY parameters are summarized in the following table.

Parameter	Description
c	Pointer to cursor.
position	The relative position of the column in the select list.
<table_parameter>	The nested table which is used to tell DBMS_SQL the datatype of the column.
cnt	The maximum number of rows to be fetched in the call to the FETCH_ROWS or EXECUTE_AND_FETCH functions.
lower_bound	The starting row (lower bound) in which column values will be placed in the nested table you provide in the corresponding call to the COLUMN_VALUE or VARIABLE_VALUE procedures.

<table_parameter> IN <table_type> is one of the following:

n_tab IN DBMS_SQL.NUMBER_TABLE c_tab IN DBMS_SQL.VARCHAR2_TABLE d_tab IN DBMS_SQL.DATE_TABLE bl_tab IN DBMS_SQL.BLOB_TABLE cl_tab IN DBMS_SQL._TABLE bf_tab IN DBMS_SQL.BFILE_TABLE

When you call the COLUMN_VALUE or VARIABLE_VALUE procedures against an array-defined column, the Nth fetched column value will be placed in the lower_bound+N-1th row in the nested table. In other words, if you have fetched three rows and your call to DEFINE_ARRAY looked like this:

DECLARE    datetab DBMS_SQL.DATE_TABLE; BEGIN    DBMS_SQL.DEFINE_ARRAY (cur, 2, datetab, 10, 15);
...execute and fetch rows...
     DBMS_SQL.COLUMN_VALUE (cur, 2, datetab); END;

then the data will be placed in datetab(15), datetab(16), and datetab(17).

2.3.6.1 The DBMS_SQL.EXECUTE function

The EXECUTE function executes the SQL statement associated with the specified cursor,

FUNCTION DBMS_SQL.EXECUTE (c IN INTEGER) RETURN INTEGER;

where c is the pointer to the cursor. This function returns the number of rows processed by the SQL statement if that statement is an UPDATE, INSERT, or DELETE. For all other SQL (queries and DDL) and PL/SQL statements, the value returned by EXECUTE is undefined and should be ignored.

If the SQL statement is a query, you can now call the FETCH_ROWS function to fetch rows that are retrieved by that query. If you are executing a query, you can also use EXECUTE_AND_FETCH to execute the cursor and fetch one or more rows with a single program call.

2.3.7.1 The DBMS_SQL.FETCH_ROWS function

The FETCH_ROWS function corresponds to the FETCH statement for regular PL/SQL cursors. It fetches the next N rows from the cursor (a maximum of one if not using array processing in PL/SQL8). Here's the specification for the function,

FUNCTION DBMS_SQL.FETCH_ROWS    (c IN INTEGER) RETURN INTEGER;

where c is the pointer to the cursor. The function returns 0 when there are no more rows to fetch. You can therefore use FETCH_ROWS much as you would FETCH and the %FOUND (or %NOTFOUND) attributes. The following two sets of statements are equivalent:

• Use a normal, static cursor:

     FETCH emp_cur INTO emp_rec;    IF emp_cur%FOUND    THEN        ... process data ...    END IF;

• Use DBMS_SQL to fetch rows:

     IF DBMS_SQL.FETCH_ROWS (c) > 0    THEN       ... process data ...    END IF;

So that happens when you fetch past the end of the cursor's result set? With static cursors, you can fetch all you want and never raise an error. In the following block, for example, I fetch 1000 times from a table with 14 rows. (C'mon, you knew that, right? The emp table has 14 rows.)

DECLARE    CURSOR empcur IS SELECT * FROM emp;    emprec empcur%ROWTYPE; BEGIN    OPEN empcur;    FOR rowind IN 1 .. 1000    LOOP       FETCH empcur INTO emprec;    END LOOP; END; /

No problem -- and no exceptions! After the fourteenth fetch, the FETCH statement simply does nothing (and the record continues to hold the fourteenth row's information).

However, the "fetch past last record" behavior with dynamic SQL is different. The FETCH_ROWS function will raise the ORA-01002 exception: fetch out of sequence, if you fetch again after a call to FETCH_ROWS has returned 0. The following anonymous block raises the ORA-01002 error, because there are only three employees in department 10:

DECLARE    cur PLS_INTEGER := DBMS_SQL.OPEN_CURSOR;    fdbk PLS_INTEGER; BEGIN    DBMS_SQL.PARSE        (cur, 'SELECT * FROM emp WHERE deptno = 10', DBMS_SQL.NATIVE);     fdbk := DBMS_SQL.EXECUTE_CURSOR (cur);    FOR Nfetch IN 1 .. 5    LOOP       /* On fetch #5 this will raise ORA-01002 */       fdbk := DBMS_SQL.FETCH_ROWS (cur);    END LOOP;    DBMS_SQL.CLOSE_CURSOR (cur); END; /

The following procedure shows how you can employ the FETCH_ROWS logic inside of a loop to fetch each of the rows from a cursor and place column values in an Oracle Forms block:

/* Filename on companion disk:

fillblck.fp */ PROCEDURE fill_block (where_clause_in IN VARCHAR2) /* || Query data from table using a dynamic where clause and then || pass those values to an Oracle Forms block. */ IS    /*     || Declare cursor handle and parse the query, all in a single    || statement using open_and_parse (see PARSE description).    */    c INTEGER := DBMS_SQL.OPEN_CURSOR;     emprec employee%ROWTYPE;     /* return value from EXECUTE; ignore in case of query */    fdbk INTEGER; BEGIN    /* Parse the query  with a dynamic WHERE clause */    DBMS_SQL.PARSE (c,        'SELECT employee_id, last_name ' ||       '  FROM employee WHERE ' || where_clause_in,       DBMS_SQL.NATIVE);     /* Define the columns in the cursor for this query */    DBMS_SQL.DEFINE_COLUMN (c, 1, emprec.empno);    DBMS_SQL.DEFINE_COLUMN (c, 2, emprec.ename, 30);     /* Now I can execute the query */    fdbk:= DBMS_SQL.EXECUTE (c);    LOOP       /* Try to fetch next row. If done, then exit the loop. */       EXIT WHEN DBMS_SQL.FETCH_ROWS (c) = 0;       /*       || Retrieve data via calls to COLUMN_VALUE and place those       || values in a new record in the block.       */       DBMS_SQL.COLUMN_VALUE (c, 1, emprec.empno);       DBMS_SQL.COLUMN_VALUE (c, 2, emprec.ename);       CREATE_RECORD;       :employee.employee_id := emprec.empno;       :employee.employee_nm := emprec.ename;    END LOOP;     /* Clean up the cursor */    DBMS_SQL.CLOSE_CURSOR (c); END;

In this example, you can fetch only one row at a time, because you defined each of your columns in the cursor to hold a single value. If, on the other hand, you defined a column as an array, then the fetch could receive multiple rows in a single call. This approach is explored in more detail in the section Section 2.5.6, "Array Processing with DBMS_SQL" ."

2.3.7.2 The DBMS_SQL.EXECUTE_AND_FETCH function

The EXECUTE_AND_FETCH function executes the SELECT statement associated with the specified cursor and immediately fetches the rows associated with the query. Here's the specification for the function.

FUNCTION DBMS_SQL.EXECUTE_AND_FETCH     (c IN INTEGER     ,exact IN BOOLEAN DEFAULT FALSE) RETURN INTEGER;

Parameters are summarized in the following table.

Parameter	Description
c	The handle or pointer to the cursor originally returned by a call to OPEN_CURSOR.
exact	Set to TRUE if you want the function to raise an exception when it fetches more than one row.

Even if EXECUTE_AND_FETCH does raise an exception (TOO_MANY_ROWS), the rows will still be fetched and available. The value returned by the function will, however, be NULL.

This function is designed to make it easy to execute and fetch a single row from a query. It is very similar to the implicit SELECT cursor in native PL/SQL, which either returns a single row, multiple rows (for PL/SQL8 array access only), or raises the TOO_MANY_ROWS exception (ORA-01422).

See the sidebar entitled the sidebar "Oracle: The Show Me Technology" ," for a script you can use to examine the behavior of this built-in function.

2.3.8.1 The DBMS_SQL.COLUMN_VALUE procedure

The COLUMN_VALUE procedure retrieves a value from the cursor into a local variable. Use this procedure when the SQL statement is a query and you are fetching rows with EXECUTE_AND_FETCH or FETCH_ROWS. You can retrieve the value for a single column in a single row or, with PL/SQL8, you can retrieve the values for a single column across multiple rows fetched. The header for the single-row version of the procedure is as follows:

 PROCEDURE DBMS_SQL.COLUMN_VALUE  (c IN INTEGER,      position IN INTEGER,      value OUT <datatype>,     [, column_error OUT NUMBER]      [, actual_length OUT INTEGER ]);

The COLUMN_VALUE parameters are summarized in the following table.

Parameter	Description
c	Pointer to the cursor.
position	Relative position of the column in the select list.
value	The PL/SQL structure that receives the column value. If the <datatype> of this argument does not match that of the cursor's column, DBMS_SQL will raise the DBMS_SQL.INCONSISTENT_DATATYPE exception.
<table_parameter>	The PL/SQL table (of type <table_type>) holding one or more colum values, depending on how many rows were previously fetched.
column_error	Returns an error code for the specified value (the value might be too large for the variable, for instance).
actual_length	Returns the actual length of the returned value before any truncation takes place (due to a difference in size between the retrieved value in the cursor and the variable).

<datatype> can be one of the following types:

NUMBER DATE MLSLABEL VARCHAR2 CHARACTER SET ANY_CS BLOB CLOB CHARACTER SET ANY_CS BFILE

The header for the multiple-row version of COLUMN_VALUE is as follows:

PROCEDURE DBMS_SQL.COLUMN_VALUE    (c IN INTEGER,      position IN INTEGER,      <table_parameter> OUT <table_type>);

<table_parameter> OUT <table_type> can be one of the following:

n_tab OUT DBMS_SQL.NUMBER_TABLE c_tab OUT DBMS_SQL.VARCHAR2_TABLE d_tab OUT DBMS_SQL.DATE_TABLE bl_tab OUT DBMS_SQL.BLOB_TABLE cl_tab OUT DBMS_SQL.CLOB_TABLE bf_tab OUT DBMS_SQL.BFILE_TABLE

The DBMS_SQL package also offers more specific variants of COLUMN_VALUE for less common datatype:

PROCEDURE DBMS_SQL.

COLUMN_VALUE_CHAR    (c IN INTEGER,      position IN INTEGER,      value OUT CHAR,     [, column_error OUT NUMBER]      [, actual_length OUT INTEGER ]);  PROCEDURE DBMS_SQL.

COLUMN_VALUE_RAW    (c IN INTEGER,      position IN INTEGER,      value OUT RAW,     [, column_error OUT NUMBER]      [, actual_length OUT INTEGER ]);  PROCEDURE DBMS_SQL.

COLUMN_VALUE_ROWID    (c IN INTEGER,      position IN INTEGER,      value OUT ROWID,     [, column_error OUT NUMBER]      [, actual_length OUT INTEGER ]);

You call COLUMN_VALUE after a row has been fetched to transfer the value from the SELECT list of the cursor into a local variable. For each call to the single-row COLUMN_VALUE, you should have made a call to DEFINE_COLUMN in order to define that column in the cursor. If you want to use the multiple-row version of COLUMN_VALUE, use the DEFINE_ARRAY procedure to define that column as capable of holding an array of values.

The following procedure displays employees by defining a cursor with two columns and, after fetching a row, calls COLUMN_VALUE to retrieve both column values:

/* Filename on companion disk:

showemps.sp */ CREATE OR REPLACE PROCEDURE showemps (where_in IN VARCHAR2 := NULL) IS    cur INTEGER := DBMS_SQL.OPEN_CURSOR;    rec emp%ROWTYPE;    fdbk INTEGER; BEGIN    DBMS_SQL.PARSE      (cur, 'SELECT empno, ename FROM emp ' ||             ' WHERE ' || NVL (where_in, '1=1'),       DBMS_SQL.NATIVE);     DBMS_SQL.DEFINE_COLUMN (cur, 1, rec.empno);    DBMS_SQL.DEFINE_COLUMN (cur, 2, rec.ename, 30);     fdbk := DBMS_SQL.EXECUTE (cur);    LOOP       /* Fetch next row. Exit when done. */       EXIT WHEN DBMS_SQL.FETCH_ROWS (cur) = 0;       DBMS_SQL.COLUMN_VALUE (cur, 1, rec.empno);       DBMS_SQL.COLUMN_VALUE (cur, 2, rec.ename);       DBMS_OUTPUT.PUT_LINE (TO_CHAR (rec.empno) || '=' || rec.ename);    END LOOP;     DBMS_SQL.CLOSE_CURSOR (cur); END; /

This next PL/SQL8 block fetches the hiredate and employee ID for all rows in the emp table and deposits values into two separate PL/SQL tables. Notice that since I know there are just 14 rows in the emp table, I need only one call to the EXECUTE_AND_FETCH function to fetch all rows.

/* Filename on companion disk:

arrayemp.sp */ CREATE OR REPLACE PROCEDURE showall IS    cur INTEGER := DBMS_SQL.OPEN_CURSOR;    fdbk INTEGER;     empno_tab DBMS_SQL.NUMBER_TABLE;    hiredate_tab DBMS_SQL.DATE_TABLE; BEGIN    DBMS_SQL.PARSE      (cur, 'SELECT empno, hiredate FROM emp', DBMS_SQL.NATIVE);     /* Allow fetching of up to 100 rows. */    DBMS_SQL.DEFINE_ARRAY (cur, 1, empno_tab, 100, 1);    DBMS_SQL.DEFINE_ARRAY (cur, 2, hiredate_tab, 100, 1);     fdbk := DBMS_SQL.EXECUTE_AND_FETCH (cur);     /* This will show total numbers of rows fetched. */    DBMS_OUTPUT.PUT_LINE (fdbk);        /* Get values for all rows in one call. */    DBMS_SQL.COLUMN_VALUE (cur, 1, empno_tab);    DBMS_SQL.COLUMN_VALUE (cur, 2, hiredate_tab);        FOR rowind IN empno_tab.FIRST .. empno_tab.LAST    LOOP       DBMS_OUTPUT.PUT_LINE (empno_tab(rowind));       DBMS_OUTPUT.PUT_LINE (hiredate_tab(rowind));    END LOOP;        DBMS_SQL.CLOSE_CURSOR (cur); END; /

The Section 2.5, "DBMS_SQL Examples" " section provides other examples of array processing in DBMS_SQL.

2.3.8.2 The DBMS_SQL. COLUMN_VALUE_LONG procedure

DBMS_SQL provides a separate procedure, COLUMN_VALUE_LONG, to allow you to retrieve LONG values from a dynamic query. The header for this program is as follows:

PROCEDURE DBMS_SQL.COLUMN_VALUE_LONG     (c IN INTEGER     ,position IN INTEGER     ,length IN INTEGER     ,offset IN INTEGER     ,value OUT VARCHAR2     ,value_length OUT INTEGER);

The COLUMN_VALUE_LONG parameters are summarized in the following table.

Parameter	Description
c	Pointer to the cursor.
position	Relative position of the column in the select list.
length	The length in bytes of the portion of the LONG value to be retrieved.
offset	The byte position in the LONG column at which the retrieval is to start.
value	The variable that will receive part or all of the LONG column value.
value_length	The actual length of the retrieved value.

The COLUMN_VALUE_LONG procedure offers just about the only way to obtain a LONG value from the database and move it into PL/SQL data structures in your program. You cannot rely on a static SELECT to do this. Instead, use DBMS_SQL and both the DEFINE_COLUMN_LONG and COLUMN_VALUE_LONG procedures.

The following example demonstrates the technique, and, in the process, offers a generic procedure called dump_long that you can use to dump the contents of a long column in your table into a local PL/SQL table. The dump_long procedure accepts a table name, column name, and optional WHERE clause. It returns a PL/SQL table with the LONG value broken up into 256-byte chunks.

/* Filename on companion disk:

dumplong.sp */ CREATE OR REPLACE PROCEDURE dump_long (    tab IN VARCHAR2,    col IN VARCHAR2,    whr IN VARCHAR2 := NULL,    pieces IN OUT DBMS_SQL.VARCHAR2S) /* Requires Oracle 7.3 or above */ IS    cur PLS_INTEGER := DBMS_SQL.OPEN_CURSOR;    fdbk PLS_INTEGER;     TYPE long_rectype IS RECORD (       piece_len PLS_INTEGER,       pos_in_long PLS_INTEGER,       one_piece VARCHAR2(256),       one_piece_len PLS_INTEGER       );    rec long_rectype;    BEGIN        if whr is NULL */    DBMS_SQL.PARSE (       cur,       'SELECT ' || col ||        '  FROM ' || tab ||       ' WHERE ' || NVL (whr, '1 = 1'),       DBMS_SQL.NATIVE);     /* Define the long column and then execute and fetch... */    DBMS_SQL.DEFINE_COLUMN_LONG (cur, 1);    fdbk := DBMS_SQL.EXECUTE (cur);    fdbk := DBMS_SQL.FETCH_ROWS (cur);     /* If a row was fetched, loop through the long value until     || all pieces are retrieved.    */    IF fdbk > 0    THEN       rec.piece_len := 256;       rec.pos_in_long := 0;       LOOP          DBMS_SQL.COLUMN_VALUE_LONG (             cur,             1,             rec.piece_len,             rec.pos_in_long,             rec.one_piece,             rec.one_piece_len);          EXIT WHEN rec.one_piece_len = 0;           /* Always put the new piece in the next available row */          pieces (NVL (pieces.LAST, 0) + 1) := rec.one_piece;          rec.pos_in_long := rec.pos_in_long + rec.one_piece_len;       END LOOP;    END IF;    DBMS_SQL.CLOSE_CURSOR (cur); END; /

To test this procedure, I created a table with a LONG column as follows (the table creation, INSERT, and test script may all be found in dumplong.tst):

DROP TABLE nextbook; CREATE TABLE nextbook     (title VARCHAR2(100), text LONG); INSERT INTO nextbook VALUES      ('Oracle PL/SQL Quick Reference',     RPAD ('INSTR ', 256, 'blah1 ') ||     RPAD ('SUBSTR ', 256, 'blah2 ') ||     RPAD ('TO_DATE ', 256, 'blah3 ') ||     RPAD ('TO_CHAR ', 256, 'blah4 ') ||     RPAD ('LOOP ', 256, 'blah5 ') ||     RPAD ('IF ', 256, 'blah6 ') ||     RPAD ('CURSOR ', 256, 'blah7 ')      );

I then put together this short test script. It extracts the single value from the table. (I pass a NULL WHERE clause, so it simply returns the first -- and only -- row fetched.) It then uses a numeric FOR loop to scan through the returned table to display the results.

  DECLARE    mytab DBMS_SQL.VARCHAR2S; BEGIN    dump_long ('nextbook', 'text', NULL, mytab);    FOR longind IN 1 .. mytab.COUNT    LOOP       DBMS_OUTPUT.PUT_LINE  (SUBSTR (mytab(longind), 1, 60));    END LOOP; END; /

Here is the output displayed in my SQL*Plus window:

INSTR blah1 blah1 blah1 blah1 blah1 blah1 blah1 blah1 blah1 SUBSTR blah2 blah2 blah2 blah2 blah2 blah2 blah2 blah2 blah2 TO_DATE blah3 blah3 blah3 blah3 blah3 blah3 blah3 blah3 blah TO_CHAR blah4 blah4 blah4 blah4 blah4 blah4 blah4 blah4 blah LOOP blah5 blah5 blah5 blah5 blah5 blah5 blah5 blah5 blah5 b IF blah6 blah6 blah6 blah6 blah6 blah6 blah6 blah6 blah6 bla CURSOR blah7 blah7 blah7 blah7 blah7 blah7 blah7 blah7

blah7

2.3.8.3 The DBMS_SQL.VARIABLE_VALUE procedure

The VARIABLE_VALUE procedure retrieves the value of a named variable from the specified PL/SQL block. You can retrieve the value for a single variable, or, with PL/SQL8, you can retrieve the values for an array or PL/SQL table of values. This is the header for the single-row version of the procedure:

PROCEDURE DBMS_SQL.VARIABLE_VALUE     (c IN INTEGER     ,name IN VARCHAR2     ,value OUT <datatype>);

The VARIABLE_VALUE parameters are summarized in the following table.

Parameter	Description
c	The handle or pointer to the cursor originally returned by a call to OPEN_CURSOR.
name	The name of the host variable included in the PL/SQL statement passed to PARSE.
value	The PL/SQL data structure (either a scalar variable, <datatype>, or a PL/SQL table, <table_type>) that receives the value from the cursor.

<datatype> can be one of the following:

NUMBER DATE MLSLABEL VARCHAR2 CHARACTER SET ANY_CS BLOB CLOB CHARACTER SET ANY_CS BFILE

The header for the multiple-row version of VARIABLE_VALUE is the following:

PROCEDURE DBMS_SQL.VARIABLE_VALUE     (c IN INTEGER     ,name IN VARCHAR2     ,value IN <table_type>);

<table_type> can be one of the following:

DBMS_SQL.NUMBER_TABLE DBMS_SQL.VARCHAR2_TABLE DBMS_SQL.DATE_TABLE DBMS_SQL.BLOB_TABLE DBMS_SQL.CLOB_TABLE DBMS_SQL.BFILE_TABLE

The DBMS_SQL package also offers more specific variants of VARIABLE_VALUE for less common datatypes:

PROCEDURE DBMS_SQL.VARIABLE_VALUE_CHAR     (c IN INTEGER     ,name IN VARCHAR2     ,value OUT CHAR CHARACTER SET ANY_CS);  PROCEDURE DBMS_SQL.VARIABLE_VALUE_RAW     (c IN INTEGER     ,name IN VARCHAR2     ,value OUT RAW);  PROCEDURE DBMS_SQL.VARIABLE_VALUE_ROWID     (c IN INTEGER     ,name IN VARCHAR2     ,value OUT ROWID);

If you use the multiple-row version of VARIABLE_VALUE, you must have used the BIND_ARRAY procedure to define the bind variable in the PL/SQL block as an array of values.

The following program allows you to provide the name of a stored procedure, a list of IN parameters, and a single OUT variable. It then uses dynamic PL/SQL to construct and execute that stored procedure, and finally retrieves the OUT value and returns it to the calling block.

/* Filename on companion disk:

runprog.sp */ CREATE OR REPLACE PROCEDURE runproc     (proc IN VARCHAR2, arglist IN VARCHAR2, outval OUT NUMBER) IS    cur INTEGER := DBMS_SQL.OPEN_CURSOR;    fdbk INTEGER; BEGIN    DBMS_SQL.PARSE      (cur, 'BEGIN ' || proc || '(' || arglist || ', :outparam); END;',        DBMS_SQL.NATIVE);     DBMS_SQL.BIND_VARIABLE (cur, 'outparam', 1);     fdbk := DBMS_SQL.EXECUTE (cur);        DBMS_SQL.VARIABLE_VALUE (cur, 'outparam', outval);        DBMS_SQL.CLOSE_CURSOR (cur); END; /

Now if I have the following procedure defined:

CREATE OR REPLACE PROCEDURE testdyn     (in1 IN NUMBER, in2 IN DATE, out1 OUT NUMBER) IS BEGIN    out1 := in1 + TO_NUMBER (TO_CHAR (in2, 'YYYY')); END; /

Then I can execute testdyn dynamically as follows:

DECLARE    n NUMBER; BEGIN     runproc ('testdyn', '1, sysdate', n);     DBMS_OUTPUT.PUT_LINE (n); END; /

As you have likely discerned, this is not a very good general-purpose program. It will work only with procedures that have parameter lists in which the last argument is a numeric OUT parameter and that argument must be the only OUT or IN OUT parameter in the list.

There can be many complications when attempting to execute dynamic PL/SQL. For suggestions on how best to perform these tasks, see the "Tips on Using Dynamic SQL" section.

2.3.9.1 The DBMS_SQL. CLOSE_CURSOR procedure

The CLOSE_CURSOR procedure closes the specified cursor and sets the cursor handle to NULL. It releases all memory associated with the cursor. The specification for the procedure is,

PROCEDURE DBMS_SQL.CLOSE_CURSOR     (c IN OUT INTEGER);

where c is the handle or pointer to the cursor that was originally returned by a call to OPEN_CURSOR. The parameter is IN OUT because once the cursor is closed, the pointer is set to NULL.

If you try to close a cursor that is not open or that is not a valid cursor ID, this program will raise the INVALID_CURSOR exception. You might consider building a "wrapper" for CLOSE_CURSOR to avoid this exception.

CREATE OR REPLACE PROCEDURE closeif (c IN OUT INTEGER) IS BEGIN    IF DBMS_SQL.IS_OPEN (c)    THEN       DBMS_SQL.CLOSE_CURSOR (c);     END IF; END; /

2.3.10.1 The DBMS_SQL. LAST_ERROR_POSITION function

The LAST_ERROR_POSITION function returns the byte offset in the SQL statement where the error occurred. The first character in the statement is at position 0. This function offers the same kind of feedback SQL*Plus offers you when it displays a syntax or value error while executing a SQL statement: it displays the problematic text with an asterisk (*) under the character that caused the problem. Here's the specification for this function:

FUNCTION DBMS_SQL.LAST_ERROR RETURN INTEGER;

You must call this function immediately after a call to EXECUTE or EXECUTE_AND_FETCH in order to obtain meaningful results. The following script demonstrates when and how this function's return value can come in handy:

/* Filename on companion disk: file

 errpos.sql */* DECLARE       cur BINARY_INTEGER := DBMS_SQL.OPEN_CURSOR;    errpos BINARY_INTEGER;    fdbk BINARY_INTEGER; BEGIN    DBMS_SQL.PARSE (cur, 'SELECT empno, ^a FROM emp', DBMS_SQL.NATIVE);    DBMS_SQL.DEFINE_COLUMN (cur, 1, 1);    fdbk := DBMS_SQL.EXECUTE_AND_FETCH (cur, false);    DBMS_SQL.CLOSE_CURSOR (cur); EXCEPTION    WHEN OTHERS     THEN       errpos := DBMS_SQL.LAST_ERROR_POSITION;       DBMS_OUTPUT.PUT_LINE (SQLERRM || ' at pos ' || errpos);       DBMS_SQL.CLOSE_CURSOR (cur); END; /

When I run this script in SQL*Plus, I get the following output:

SQL> @errpos ORA-00936: missing expression at pos 14

One of the greatest frustrations with dynamic SQL is getting your string strung together improperly. It is very easy to introduce syntax errors. The DBMS_SQL.LAST_ERROR_POSITION function can be a big help in uncovering the source of your problem.

NOTE: Some readers may be wondering why I declared a local variable called errpos and assigned the value to it before calling DBMS_OUTPUT.PUT_LINE to examine the error. The reason (discovered by Eric Givler, ace technical reviewer for this book) is that if I do not grab the value from this function before calling SQLERRM, the function will return 0 instead of the 14 for which I am looking.

If my exception section looks, for example, as follows,

   WHEN OTHERS     THEN       DBMS_OUTPUT.PUT_LINE           (SQLERRM || ' at pos ' || DBMS_SQL.LAST_ERROR_POSITION);       DBMS_SQL.CLOSE_CURSOR (cur);

then the output from running the program will become:

SQL> @errpos ORA-00936: missing expression at pos 0

Why does this happen? The SQLERRM function must be executing an implicit SQL statement (probably a query!). This action resets the values returned by this DBMS_SQL function, since it is tied to the underlying, generic implicit cursor attribute.

2.3.10.2 The DBMS_SQL.LAST_ROW_COUNT function

The LAST_ROW_COUNT function returns the total number of rows fetched at that point. This function corresponds to the %ROWCOUNT attribute of a normal, static cursor in PL/SQL. Here's the specification for this function:

FUNCTION DBMS_SQL.LAST_ROW_COUNT RETURN INTEGER;

You must call this function immediately after a call to EXECUTE_AND_FETCH or FETCH_ROWS in order to obtain meaningful results. You will most likely use this function when fetching from within a loop:

CREATE OR REPLACE PROCEDURE show_n_emps (lim IN INTEGER) IS    cur PLS_INTEGER := DBMS_SQL.OPEN_CURSOR;    fdbk PLS_INTEGER;    v_ename emp.ename%TYPE; BEGIN    DBMS_SQL.PARSE (cur, 'SELECT ename FROM emp', DBMS_SQL.NATIVE);    DBMS_SQL.DEFINE_COLUMN (cur, 1, v_ename, 100);    fdbk := DBMS_SQL.EXECUTE (cur);    LOOP       EXIT WHEN DBMS_SQL.FETCH_ROWS (cur) = 0;       IF DBMS_SQL.LAST_ROW_COUNT <= lim       THEN          DBMS_SQL.COLUMN_VALUE (cur, 1, v_ename);          DBMS_OUTPUT.PUT_LINE (v_ename);       ELSE          /* Hit maximum. Display message and exit. */          DBMS_OUTPUT.PUT_LINE              ('Displayed ' || TO_CHAR (lim) || ' employees.');          EXIT;       END IF;    END LOOP;    DBMS_SQL.CLOSE_CURSOR (cur); END; /

2.3.10.3 The DBMS_SQL.LAST_ROW_ID function

The LAST_ROW_ID function returns the ROWID of the row fetched most recently. The specification for this function is as follows:

FUNCTION DBMS_SQL.LAST_ROW_ID RETURN ROWID;

You must call this function immediately after a call to EXECUTE_AND_FETCH or FETCH_ROWS in order to obtain meaningful results. This function is useful mostly for debugging purposes and perhaps to log which records have been affected.

2.3.10.4 The DBMS_SQL.LAST_SQL_FUNCTION_CODE function

The LAST_SQL_FUNCTION_CODE function returns the SQL function code for the SQL statement. The specification for this function is as follows:

FUNCTION DBMS_SQL.LAST_SQL_FUNCTION_CODE RETURN INTEGER;

You must call this function immediately after a call to EXECUTE_AND_FETCH or EXECUTE in order to obtain meaningful results. It will tell you which type of SQL statement was executed.

The SQL function codes are listed in Table 2.3 .

Table 2.3: SQL Function Codes

Code	SQL Function	Code	SQL Function	Code	SQL Function
01	CREATE TABLE	35	LOCK	69	(NOT USED)
02	SET ROLE	36	NOOP	70	ALTER RESOURCE COST
03	INSERT	37	RENAME	71	CREATE SNAPSHOT LOG
04	SELECT	38	COMMENT	72	ALTER SNAPSHOT LOG
05	UPDATE	39	AUDIT	73	DROP SNAPSHOT LOG
06	DROP ROLE	40	NO AUDIT	74	CREATE SNAPSHOT
07	DROP VIEW	41	ALTER INDEX	75	ALTER SNAPSHOT
08	DROP TABLE	42	CREATE EXTERNAL DATABASE	76	DROP SNAPSHOT
09	DELETE	43	DROP EXTERNAL DATABASE	77	CREATE TYPE
10	CREATE VIEW	44	CREATE DATABASE	78	DROP TYPE
11	DROP USER	45	ALTER DATABASE	79	ALTER ROLE
12	CREATE ROLE	46	CREATE ROLLBACK SEGMENT	80	ALTER TYPE
13	CREATE SEQUENCE	47	ALTER ROLLBACK SEGMENT	81	CREATE TYPE BODY
14	ALTER SEQUENCE	48	DROP ROLLBACK SEGMENT	82	ALTER TYPE BODY
15	(NOT USED)	49	CREATE TABLESPACE	83	DROP TYPE BODY
16	DROP SEQUENCE	50	ALTER TABLESPACE	84	DROP LIBRARY
17	CREATE SCHEMA	51	DROP TABLESPACE	85	TRUNCATE TABLE
18	CREATE CLUSTER	52	ALTER SESSION	86	TRUNCATE CLUSTER
19	CREATE USER	53	ALTER USER	87	CREATE BITMAPFILE
20	CREATE INDEX	54	COMMIT (WORK)	88	ALTER VIEW
21	DROP INDEX	55	ROLLBACK	89	DROP BITMAPFILE
22	DROP CLUSTER	56	SAVEPOINT	90	SET CONSTRAINTS
23	VALIDATE INDEX	57	CREATE CONTROL FILE	91	CREATE FUNCTION
24	CREATE PROCEDURE	58	ALTER TRACING	92	ALTER FUNCTION
25	ALTER PROCEDURE	59	CREATE TRIGGER	93	DROP FUNCTION
26	ALTER TABLE	60	ALTER TRIGGER	94	CREATE PACKAGE
27	EXPLAIN	61	DROP TRIGGER	95	ALTER PACKAGE
28	GRANT	62	ANALYZE TABLE	96	DROP PACKAGE
29	REVOKE	63	ANALYZE INDEX	97	CREATE PACKAGE BODY
30	CREATE SYNONYM	64	ANALYZE CLUSTER	98	ALTER PACKAGE BODY
31	DROP SYNONYM	65	CREATE PROFILE	99	DROP PACKAGE BODY
32	ALTER SYSTEM SWITCH LOG	66	DROP PROFILE	157	CREATE DIRECTORY
33	SET TRANSACTION	67	ALTER PROFILE	158	DROP DIRECTORY
34	PL/SQL EXECUTE	68	DROP PROCEDURE	159	CREATE LIBRARY

2.3.11.1 The DBMS_SQL. DESCRIBE_COLUMNS procedure

The DESCRIBE_COLUMNS procedure obtains information about your dynamic cursor. Here is the header:

PROCEDURE DBMS_SQL.DESCRIBE_COLUMNS     (c IN INTEGER     ,col_cnt OUT INTEGER     ,desc_t OUT DBMS_SQL.DESC_TAB);

The parameters for the DESCRIBE_COLUMNS procedure are summarized in the following table.

Parameter	Description
c	The pointer to the cursor.
col_cnt	The number of columns in the cursor, which equals the number of rows defined in the PL/SQL table.
desc_t	The PL/SQL table, which contains all of the column information. This is a table of records of type DBMS_SQL.DESC_REC (<table_type), which is described later.

The following table lists the DBMS_SQL.DESC_REC record type fields.

<table_type>

Datatype

Description

col_type

BINARY_INTEGER

Type of column described

col_max_len

BINARY_INTEGER

Maximum length of column value

col_name

VARCHAR2(32)

Name of the column

col_name_len

BINARY_INTEGER

Length of the column name

col_schema_name

VARCHAR2(32)

Name of column type schema if an object type

col_schema_name_len

BINARY_INTEGER

Length of schema name

col_precision

BINARY_INTEGER

Precision of column if a number

col_scale

BINARY_INTEGER

Scale of column if a number

col_charsetid

BINARY_INTEGER

ID of character set

col_charsetform

BINARY_INTEGER

Character set form

col_null_ok

BOOLEAN

TRUE if column can be NULL

The values for column types are as follows:

Datatype	Number
VARCHAR2	1
NVARCHAR2	1
NUMBER	2
INTEGER	2
LONG	8
ROWID	11
DATE	12
RAW	23
LONG RAW	24
CHAR	96
NCHAR	96
MLSLABEL	106
CLOB (Oracle8)	112
NCLOB (Oracle8)	112
BLOB (Oracle8)	113
BFILE (Oracle8)	114
Object type (Oracle8)	121
Nested table Type (Oracle8)	122
Variable array (Oracle8)	123

When you call this program, you need to have declared a PL/SQL table based on the DBMS_SQL. DESC_T. You can then use PL/SQL table methods to traverse the table and extract the needed information about the cursor. The following anonymous block shows the basic steps you will perform when working with this built-in:

DECLARE    cur PLS_INTEGER := DBMS_SQL.OPEN_CURSOR;    cols DBMS_SQL.DESC_T;    ncols PLS_INTEGER; BEGIN    DBMS_SQL.PARSE        (cur, 'SELECT hiredate, sal FROM emp', DBMS_SQL.NATIVE);    DBMS_SQL.DEFINE_COLUMN (cur, 1, SYSDATE);    DBMS_SQL.DEFINE_COLUMN (cur, 2, 1);    DBMS_SQL.DESCRIBE_COLUMNS (cur, ncols, cols);    FOR colind IN 1 .. ncols    LOOP       DBMS_OUTPUT.PUT_LINE (cols.col_name);    END LOOP;    DBMS_SQL.CLOSE_CURSOR (cur); END; /

If you are going to use this procedure to extract information about a dynamic cursor, you will likely want to build a "wrapper" around it to make it easier for you to get at this data. The Section 2.5 " section at the end of this chapter offers an example of this wrapper.
